Models
| Width | Weight per ft | Model # |
|---|---|---|
| 12" | 3 lbs | FBF-12 |
| 18" | 3 lbs | FBF-18 |
| 24" | 3 lbs | FBF-24 |
| 30" | 3 lbs | FBF-30 |
| >30" | 3 lbs | FBF-30V |
FBF
Flange Below Floor
- 16GA Type 304 Stainless Steel
- Covers the Body of the Trough on All 4 Sides
- Flange Goes Down & Out (“L” Shape)
- Polished Smooth to a #4 Brushed Satin Finish
- Floor trough & Grating Sold Separately
Download Spec Sheet
FBF 473.84 KB
Compatible Trough Models
| Models: |
|---|
| CFT – 16GA, 4″ Deep |
| FT – 14GA, 4″ Deep |
| ASFT – Anti-Splash, 14GA, 6” Deep |
| SFT – 14GA, 2” Deep |
| FWR – Floor Water Receptacle, 16GA, 4” Deep |
| NWR – 6” Wide Floor Water Receptable |
