Models

Width	Length	Weight	w/ Grid Grating	w/ Subway Grating	w/ Anti-Slip Subway Grating	Stock	AutoCAD/ Revit
12"	24"	32 lbs	SFT-1224-SQ	SFT-1224-SG	SFT-1224-SGAS	Yes	View Model
12"	30"	41 lbs	SFT-1230-SQ	SFT-1230-SG	SFT-1230-SGAS	No	View Model
12"	36"	49 lbs	SFT-1236-SQ	SFT-1236-SG	SFT-1236-SGAS	No	View Model
12"	48"	65 lbs	SFT-1248-SQ	SFT-1248-SG	SFT-1248-SGAS	Yes	View Model
12"	60"	81 lbs	SFT-1260-SQ	SFT-1260-SG	SFT-1260-SGAS	No	View Model
12"	72"	97 lbs	SFT-1272-SQ	SFT-1272-SG	SFT-1272-SGAS	No	View Model
12"	84"	113 lbs	SFT-1284-SQ	SFT-1284-SG	SFT-1284-SGAS	No	View Model
12"	96"	130 lbs	SFT-1296-SQ	SFT-1296-SG	SFT-1296-SGAS	No	View Model
12"	108"	146 lbs	SFT-12108-SQ	SFT-12108-SG	SFT-12108-SGAS	No	View Model
12"	120"	162 lbs	SFT-12120-SQ	SFT-12120-SG	SFT-12120-SGAS	No	View Model
15" & 18"	24"	46 lbs	SFT-1824-SQ	SFT-1824-SG	SFT-1824-SGAS	No	View Model
15" & 18"	30"	58 lbs	SFT-1830-SQ	SFT-1830-SG	SFT-1830-SGAS	No	View Model
15" & 18"	36"	68 lbs	SFT-1836-SQ	SFT-1836-SG	SFT-1836-SGAS	No	View Model
15" & 18"	48"	89 lbs	SFT-1848-SQ	SFT-1848-SG	SFT-1848-SGAS	No	View Model
15" & 18"	60"	114 lbs	SFT-1860-SQ	SFT-1860-SG	SFT-1860-SGAS	No	View Model
15" & 18"	72"	137 lbs	SFT-1872-SQ	SFT-1872-SG	SFT-1872-SGAS	No	View Model
15" & 18"	84"	160 lbs	SFT-1884-SQ	SFT-1884-SG	SFT-1884-SGAS	No	View Model
15" & 18"	96"	182 lbs	SFT-1896-SQ	SFT-1896-SG	SFT-1896-SGAS	No	View Model
15" & 18"	108"	205 lbs	SFT-18108-SQ	SFT-18108-SG	SFT-18108-SGAS	No	View Model
15" & 18"	120"	228 lbs	SFT-18120-SQ	SFT-18120-SG	SFT-18120-SGAS	No	View Model
21" & 24"	24"	63 lbs	SFT-2424-SQ	SFT-2424-SG	SFT-2424-SGAS	No	View Model
21" & 24"	30"	79 lbs	SFT-2430-SQ	SFT-2430-SG	SFT-2430-SGAS	No	View Model
21" & 24"	36"	94 lbs	SFT-2436-SQ	SFT-2436-SG	SFT-2436-SGAS	No	View Model
21" & 24"	48"	126 lbs	SFT-2448-SQ	SFT-2448-SG	SFT-2448-SGAS	No	View Model
21" & 24"	60"	157 lbs	SFT-2460-SQ	SFT-2460-SG	SFT-2460-SGAS	No	View Model
21" & 24"	72"	188 lbs	SFT-2472-SQ	SFT-2472-SG	SFT-2472-SGAS	No	View Model
21" & 24"	84"	220 lbs	SFT-2484-SQ	SFT-2484-SG	SFT-2484-SGAS	No	View Model
21" & 24"	96"	251 lbs	SFT-2496-SQ	SFT-2496-SG	SFT-2496-SGAS	No	View Model
21" & 24"	108"	283 lbs	SFT-24108-SQ	SFT-24108-SG	SFT-24108-SGAS	No	View Model
21" & 24"	120"	314 lbs	SFT-24120-SQ	SFT-24120-SG	SFT-24120-SGAS	No	View Model
30"	24"	80 lbs	SFT-3024-SQ	SFT-3024-SG	SFT-3024-SGAS	No	View Model
30"	30"	101 lbs	SFT-3030-SQ	SFT-3030-SG	SFT-3030-SGAS	No	View Model
30"	36"	120 lbs	SFT-3036-SQ	SFT-3036-SG	SFT-3036-SGAS	No	View Model
30"	48"	160 lbs	SFT-3048-SQ	SFT-3048-SG	SFT-3048-SGAS	No	View Model
30"	60"	200 lbs	SFT-3060-SQ	SFT-3060-SG	SFT-3060-SGAS	No	View Model
30"	72"	240 lbs	SFT-3072-SQ	SFT-3072-SG	SFT-3072-SGAS	No	View Model
30"	84"	280 lbs	SFT-3084-SQ	SFT-3084-SG	SFT-3084-SGAS	No	View Model
30"	96"	320 lbs	SFT-3096-SQ	SFT-3096-SG	SFT-3096-SGAS	No	View Model
30"	108"	360 lbs	SFT-30108-SQ	SFT-30108-SG	SFT-30108-SGAS	No	View Model
30"	120"	400 lbs	SFT-30120-SQ	SFT-30120-SG	SFT-30120-SGAS	No	View Model

Width	Length	Weight	w/ ADA Subway Grating	w/ Fiberglass Grating	w/ ADA Fiberglass Grating	Stock	AutoCAD/ Revit
12"	24"	46 lbs	SFT-1224-SG-ADA	SFT-1224-PFG	SFT-1224-PFG-ADA	Yes	View Model
12"	30"	58 lbs	SFT-1230-SG-ADA	SFT-1230-PFG	SFT-1230-PFG-ADA	No	View Model
12"	36"	69 lbs	SFT-1236-SG-ADA	SFT-1236-PFG	SFT-1236-PFG-ADA	No	View Model
12"	48"	92 lbs	SFT-1248-SG-ADA	SFT-1248-PFG	SFT-1248-PFG-ADA	Yes	View Model
12"	60"	115 lbs	SFT-1260-SG-ADA	SFT-1260-PFG	SFT-1260-PFG-ADA	No	View Model
12"	72"	138 lbs	SFT-1272-SG-ADA	SFT-1272-PFG	SFT-1272-PFG-ADA	No	View Model
12"	84"	161 lbs	SFT-1284-SG-ADA	SFT-1284-PFG	SFT-1284-PFG-ADA	No	View Model
12"	96"	184 lbs	SFT-1296-SG-ADA	SFT-1296-PFG	SFT-1296-PFG-ADA	No	View Model
12"	108"	207 lbs	SFT-12108-SG-ADA	SFT-12108-PFG	SFT-12108-PFG-ADA	No	View Model
12"	120"	230 lbs	SFT-12120-SG-ADA	SFT-12120-PFG	SFT-12120-PFG-ADA	No	View Model
15" & 18"	24"	66 lbs	SFT-1824-SG-ADA	SFT-1824-PFG	SFT-1824-PFG-ADA	No	View Model
15" & 18"	30"	83 lbs	SFT-1830-SG-ADA	SFT-1830-PFG	SFT-1830-PFG-ADA	No	View Model
15" & 18"	36"	99 lbs	SFT-1836-SG-ADA	SFT-1836-PFG	SFT-1836-PFG-ADA	No	View Model
15" & 18"	48"	132 lbs	SFT-1848-SG-ADA	SFT-1848-PFG	SFT-1848-PFG-ADA	No	View Model
15" & 18"	60"	165 lbs	SFT-1860-SG-ADA	SFT-1860-PFG	SFT-1860-PFG-ADA	No	View Model
15" & 18"	72"	198 lbs	SFT-1872-SG-ADA	SFT-1872-PFG	SFT-1872-PFG-ADA	No	View Model
15" & 18"	84"	231 lbs	SFT-1884-SG-ADA	SFT-1884-PFG	SFT-1884-PFG-ADA	No	View Model
15" & 18"	96"	264 lbs	SFT-1896-SG-ADA	SFT-1896-PFG	SFT-1896-PFG-ADA	No	View Model
15" & 18"	108"	297 lbs	SFT-18108-SG-ADA	SFT-18108-PFG	SFT-18108-PFG-ADA	No	View Model
15" & 18"	120"	330 lbs	SFT-18120-SG-ADA	SFT-18120-PFG	SFT-18120-PFG-ADA	No	View Model
21" & 24"	24"	90 lbs	SFT-2424-SG-ADA	SFT-2424-PFG	SFT-2424-PFG-ADA	No	View Model
21" & 24"	30"	113 lbs	SFT-2430-SG-ADA	SFT-2430-PFG	SFT-2430-PFG-ADA	No	View Model
21" & 24"	36"	135 lbs	SFT-2436-SG-ADA	SFT-2436-PFG	SFT-2436-PFG-ADA	No	View Model
21" & 24"	48"	180 lbs	SFT-2448-SG-ADA	SFT-2448-PFG	SFT-2448-PFG-ADA	No	View Model
21" & 24"	60"	225 lbs	SFT-2460-SG-ADA	SFT-2460-PFG	SFT-2460-PFG-ADA	No	View Model
21" & 24"	72"	270 lbs	SFT-2472-SG-ADA	SFT-2472-PFG	SFT-2472-PFG-ADA	No	View Model
21" & 24"	84"	315 lbs	SFT-2484-SG-ADA	SFT-2484-PFG	SFT-2484-PFG-ADA	No	View Model
21" & 24"	96"	360 lbs	SFT-2496-SG-ADA	SFT-2496-PFG	SFT-2496-PFG-ADA	No	View Model
21" & 24"	108"	405 lbs	SFT-24108-SG-ADA	SFT-24108-PFG	SFT-24108-PFG-ADA	No	View Model
21" & 24"	120"	450 lbs	SFT-24120-SG-ADA	SFT-24120-PFG	SFT-24120-PFG-ADA	No	View Model
30"	24"	114 lbs	SFT-3024-SG-ADA	SFT-3024-PFG	SFT-3024-PFG-ADA	No	View Model
30"	30"	143 lbs	SFT-3030-SG-ADA	SFT-3030-PFG	SFT-3030-PFG-ADA	No	View Model
30"	36"	171 lbs	SFT-3036-SG-ADA	SFT-3036-PFG	SFT-3036-PFG-ADA	No	View Model
30"	48"	228 lbs	SFT-3048-SG-ADA	SFT-3048-PFG	SFT-3048-PFG-ADA	No	View Model
30"	60"	285 lbs	SFT-3060-SG-ADA	SFT-3060-PFG	SFT-3060-PFG-ADA	No	View Model
30"	72"	342 lbs	SFT-3072-SG-ADA	SFT-3072-PFG	SFT-3072-PFG-ADA	No	View Model
30"	84"	399 lbs	SFT-3084-SG-ADA	SFT-3084-PFG	SFT-3084-PFG-ADA	No	View Model
30"	96"	456 lbs	SFT-3096-SG-ADA	SFT-3096-PFG	SFT-3096-PFG-ADA	No	View Model
30"	108"	513 lbs	SFT-30108-SG-ADA	SFT-30108-PFG	SFT-30108-PFG-ADA	No	View Model
30"	120"	570 lbs	SFT-30120-SG-ADA	SFT-30120-PFG	SFT-30120-PFG-ADA	No	View Model

Width	Length	Weight	w/ Chemgrate Grating	w/ ADA Chemgrate Grating
12"	24"	46 lbs	SFT-1224-CH	SFT-1224-CH-ADA
12"	30"	58 lbs	SFT-1230-CH	SFT-1230-CH-ADA
12"	36"	69 lbs	SFT-1236-CH	SFT-1236-CH-ADA
12"	48"	92 lbs	SFT-1248-CH	SFT-1248-CH-ADA
12"	60"	115 lbs	SFT-1260-CH	SFT-1260-CH-ADA
12"	72"	138 lbs	SFT-1272-CH	SFT-1272-CH-ADA
12"	84"	161 lbs	SFT-1284-CH	SFT-1284-CH-ADA
12"	96"	184 lbs	SFT-1296-CH	SFT-1296-CH-ADA
12"	108"	207 lbs	SFT-12108-CH	SFT-12108-CH-ADA
12"	120"	230 lbs	SFT-12120-CH	SFT-12120-CH-ADA
15" & 18"	24"	66 lbs	SFT-1824-CH	SFT-1824-CH-ADA
15" & 18"	30"	83 lbs	SFT-1830-CH	SFT-1830-CH-ADA
15" & 18"	36"	99 lbs	SFT-1836-CH	SFT-1836-CH-ADA
15" & 18"	48"	132 lbs	SFT-1848-CH	SFT-1848-CH-ADA
15" & 18"	60"	165lbs	SFT-1860-CH	SFT-1860-CH-ADA
15" & 18"	72"	198 lbs	SFT-1872-CH	SFT-1872-CH-ADA
15" & 18"	84"	231 lbs	SFT-1884-CH	SFT-1884-CH-ADA
15" & 18"	96"	264 lbs	SFT-1896-CH	SFT-1896-CH-ADA
15" & 18"	108"	297 lbs	SFT-18108-CH	SFT-18108-CH-ADA
15" & 18"	120"	330 lbs	SFT-18120-CH	SFT-18120-CH-ADA
21" & 24"	24"	90 lbs	SFT-2424-CH	SFT-2424-CH-ADA
21" & 24"	30"	113 lbs	SFT-2430-CH	SFT-2430-CH-ADA
21" & 24"	36"	135 lbs	SFT-2436-CH	SFT-2436-CH-ADA
21" & 24"	48"	180 lbs	SFT-2448-CH	SFT-2448-CH-ADA
21" & 24"	60"	225 lbs	SFT-2460-CH	SFT-2460-CH-ADA
21" & 24"	72"	270 lbs	SFT-2472-CH	SFT-2472-CH-ADA
21" & 24"	84"	315 lbs	SFT-2484-CH	SFT-2484-CH-ADA
21" & 24"	96"	360 lbs	SFT-2496-CH	SFT-2496-CH-ADA
21" & 24"	108"	405 lbs	SFT-24108-CH	SFT-24108-CH-ADA
21" & 24"	120"	450 lbs	SFT-24120-CH	SFT-24120-CH-ADA
30"	24"	114 lbs	SFT-3024-CH	SFT-3024-CH-ADA
30"	30"	143 lbs	SFT-3030-CH	SFT-3030-CH-ADA
30"	36"	171 lbs	SFT-3036-CH	SFT-3036-CH-ADA
30"	48"	228 lbs	SFT-3048-CH	SFT-3048-CH-ADA
30"	60"	285 lbs	SFT-3060-CH	SFT-3060-CH-ADA
30"	72"	342 lbs	SFT-3072-CH	SFT-3072-CH-ADA
30"	84"	399 lbs	SFT-3084-CH	SFT-3084-CH-ADA
30"	96"	456 lbs	SFT-3096-CH	SFT-3096-CH-ADA
30"	108"	513 lbs	SFT-30108-CH	SFT-30108-CH-ADA
30"	120"	570 lbs	SFT-30120-CH	SFT-30120-CH-ADA

Options

Model #	Description
DOD	3”, 3½”, 5”, 6”, 8” OD Tube (Each)
AW	Additional Wastes (Each) (standard is 1 every 8’ long - included in price of trough)
ASG	Anti Splash Guards (Not for ASFT & Security Models)
BBS	Basket Beehive Strainer
BSC	Basket Strainer Cover
BSPC	Basket Strainer with Pull-Out Handle & Chain
BH	Beehive Strainers (Each) [Replacement]
BHN	Beehive Strainers for NWR (Each) [Replacement]
BSX	Beehive Strainer for Box Drain
BXD	Box Type Drain
DSE	Drain on the Side or End
GH	Grout Holes
LS	Lint Screen for Laundry Trough (Not for ASFT Model)
NCG	Non-Clog Trough (Includes Scrap Tray)
OCW	Off Center Waste (Each)
OWT	Oversize Waste Tube (Max 7”-0”)
PWT	Perforated Waste Tube (Each)
ROD	Rim on Drain (Each)
TD4	4" Threaded Drain
TD6	6" Threaded Drain
T316	T316 Drain
SSD	Secure Strainer to Drain (Tamperproof)
SF-2	Special Size Setting Flange 2” Deep (per foot)
SF-4	Special Size Setting Flange 2” to 4” Deep (per foot)
WCP	Waste Cup Strainer
WND	Weld Nipple to Drain
ST12	Scrap Tray Up to 18" Wide, 3 lbs/ft
ST20	Scrap Tray Over 18" Wide, 5 lbs/ft
GA-14	16GA up to 14GA ADD (Weight - Add: 3lbs/ft) [Per Each Gauge Change]
GA-12	14GA up to 12GA ADD (Weight - Add: 5lbs/ft) [Per Each Gauge Change]
